Since the beginning, Orion has been all about High Performance Car Audio and Hardcore Attitude… Attitude that is being hammered into the DNA of every piece of industrial-strength Orion Car Audio equipment, and the players that use and abuse it, the bass heads and boulevard bullies who will testify that the baddest car and the loudest system ride on the same chassis – theirs!! SPL competitors, world champions, hot rodders, urban cruisers and the ones that just want to have fun alike are motivated to roll with the bullet proof performance and legendary muscle that is Orion Car Audio.
- Diameter : 15 Inch
- Maximum Power : 5000 Watts
- Sensitivity : 87 dB
- Impedance : 2+2 Ohm
- RMS Power Range : 2500 Watts
- Peak Power Handling : 4000 Watts
- Shallow Mount : No Inch
- Number of Voice Coils : Dual
Power Handling
General Features
- 4” copper Wound Voice Coil on an Aluminum Former, High temperature PAARC (Polyester Amide, Amide Resin Coated)
- Continuous power handling will be 1500W (under rated)
- Burp power in excess of 5000W
- X-Max estimated at 30mm (total travel 4” peak to peak)
- Field Replaceable Cone / Voice coil / Spider Assembly
- Dual Flat Conex Spiders with Loop/Stitched Tinsel Leads
- Tall, wide, balanced, Foam (high density expanded polyester foam) surround for linear controlled long excursion using a Tri-Radius symmetrical edge design optimized on non-linear FEA
- Enhanced voice coil cooling system (forced convection – aluminum heat sinking – shorting rings to reduce inductive heating)
- Priced per speaker
- UPC: 093207061493
- Weight: 88
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
i have this 15 in my 2003 chevy s10 extreme in a custom built box with dual round 4 in ports and the amp powering this beast is an orion 2500....ok this sub is ridiculuosly loud and with this sub i out beat 2 treo 15's easily and i have no competition right now!!
-
I have two of these 15" subs and no competition. Seriously. I'm running two 2400D HCCA amps (1 per sub) and my only complaint is that I can't find enough power for them. Don't put hese in anything without a solid body-- my car's nice, and they are in my rear seat area.. and my trunk still flexes about an inch. 4 inches of excursion? Oh yeah! I can almost shake the videos off the wall at my local movie shop. Every time I tweak the amps, they just get louder. Get "Bass, I Love You" if you want to blow everyone away. Kicker? JL Audio? Rockford? Don't make me laugh. Get these subs. Today.
-
awesome sub I have 1 of the these 2 ohm dvc and man u talking about an earthshaking experience I mine is in a ported box in a 92 Acura Legend I would recommend this some to every1 who Loves Bass
-
With the right enclosure and the right amount of power this sub is the best hands down! But with low power and a bad enclosure its the worse subwoofer.
-
i have a denali with one of these and rockford 1500 amp... I just got it installed and only have my amp up 25% and i love it already.. I dont know if i'll be able to sit in the truck when i crank up the amp
-
driving with 2 of these things takes ur breath away. my boy has a setup with these subs and the bass is ridiculous. waste a money without right amps and box, definately need to ugrade vehicles electrical system to power these.
-
Got this sub in my Mazda 626. talk about hard hitting rattles everything in my house. Have a Hifonics 2400w amp pushing it and i can't say anything else but it rocks.
-
I have one of these beasts in a custom vented enclosure and it total blew me away. This sub is totally worth the money with the right box and the right amp.
-
Unfortunately words can not describe what this sub does. It really speaks for itself. There isn't anything it does not rattle. I have mine in a slot port box from fatboxusa with a Hifonics 2400. 2 Optima Redtops highoutput alternator and everytime the bass hits my volt meter on my trucks goes from 14 to 11 and dims everything. Unfortunately my amp just fried on me so I am working on getting ahold of Hifonics to have it fixed. If anything I will get an Orion amp just cause it will look better.
-
These are the best subs I ever had!!! I have them hooked up to two hifonics brutus 2600 amps with a 7.0 cubic feet box with two optima red tops and they hit harder than anything I have ever heard!!!! ORION HCCA IS THE BEST
-
i have 2 orion hcca15.2 im only playing one people think im playing 6 12s but when i show them, its unbeleivable . orion spec are garbage these subs play better in a lower tunned box trust me i have tried different tunning and right now im tunned to 28hz in a 4.5 cubic box the lows are supper low and still loud.
-
I have two of these in my 05 Dodge Dakota, with a Power Acoustick BAMF4000 on each one @ 1 ohms. I have run these speakers for hours with no problems, to me all around best sub out there, but do need there own power supply or you will be disappointed, so if you looking to get one, two, or four :) be sure to have the money to feed their power need, you never look back
-
This Is a very warm and rich sounding subwoofer that can handle extreme amounts of power. I am running a single HCCA 152 in a 3 chamber, slot port enclosure with a Hifonics Hercules 4k in my Honda Pilot. Vicious is the word I would describe the amount of pressure created by a single sub configuration. Orion HCCA is a MUST-HAVE!
-
i have 2 152s wired 1 ohm, 2 brutus 2000 in trailblazer and fixing 2 put 2 more 152s powered by lanzar 7000d at .05 ohm . with the 2 already the loudest around but want more.
