The FPR is a patented and unique in that the cone is attached directly to the spider. This design allows the spider to better control the cone movement especially its one way motion, Xmax. The angled design of the basket allows the cone to travel farther than a conventional subwoofer which would be limited by the spider's connection to the basket. Additionally, the cone utilizes a curved design where it connects to the surround. This not only advantageous as it more easily connects to the spider but it also increases the surface diameter of the cone. The increased Xmax and surface diameter gained as a result of the design allow the subwoofer to move more air and generate higher SPL.
General Features:
- Patented Shallow Design
- Increased excursion
- Superior volume displacement
- Optimized for Sealed Enclosures
- 0.60 cu ft Air Space Required
- 300W-400W RMS Power
The FPR subwoofer uses two design elements to regulate the high temperatures generated at the voice coil. Like other MTX subwoofers the FPR series uses the mechanical cooling process, Spider Plateau Venting, to continually circulate air to the voice coil eliminating distortion resulting from excessive temperatures. Additionally, the aluminum dustcap in the cone connects directly to the voice coil and transfers heat away from the voice coil further ensuring reliability and sound quality.
Extended Features:
- Add your content...Patented Flat Piston Design
- True Subwoofer Low Frequency Performance
- Spider Plateau Venting Mechanical Cooling Process Targets Cool Air at the Voice Coil
- Extended Xmax for Increased Volume Displacement
- High Roll Surround Increases Surface Diameter for Greater Volume Displacement
- Diameter : 12 Inch
- Maximum Power : 800 Watts
- Low Frequency Response : 22 Hz
- High Frequency Response : 150 Hz
- Sensitivity : 83 dB
- Impedance : 4 Ohm
- Frequency Response : 22-150 Hz
- RMS Power Range : 400 Watts
- Peak Power Handling : 800 Watts
- Shallow Mount : Yes Inch
- Number of Voice Coils : Single
- Suggested Sealed Box Volume : 0.75 Cubic ft.
- Suggested Ported Box Volume : N/A Cubic ft.
- Mounting Depth : 3.325 Inches
- Product Highlights:
- 12" shallow-mount subwoofer with single 4-ohm voice coil
- polypropylene woofer cone with rubber surround
- power range: 200-400 watts RMS (800 watts peak power)
- frequency response: 22-150 Hz
- sensitivity: 83 dB
- top-mount depth: 3-3/8"
- sealed box volume: 0.84 cubic feet
- UPC: 715442352395
- Weight: 15
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
