What's Included:
- Product Information Inside Box
- Four 3/4" #8 self-tapping screws
- Owner's Manual
- Two-channel amplifier
Product Highlights:
- 30 watts RMS x 2 at 4 ohms (60 watts RMS x 2 at 2 ohms)
- no onboard fuses — when installing multiple amps in a system, an additional 40-amp in-line fuse between the distribution block and the amplifier is recommended
- 8-3/16"W x 2-3/8"H x 7-1/8"D
- 125 watts RMS x 1 bridged at 4 ohms (4-ohm stable in bridged mode)
- differential-balanced inputs eliminate noise from your vehicle's electrical system
- variable bass boost (0-12 dB at 40 Hz)
- CEA-2006 compliant
- Class AB amp technology
- 2-channel car amplifier
- variable high- and low-pass filters (50-200 Hz, 12 dB/octave)
- preamp and speaker-level inputs
- speaker-level inputs (require speaker wire to RCA adapters)
- 8-gauge power and ground leads and a 40-amp fuse recommended — wiring and hardware not included with amplifier
- Maximum Power : 250 Watts
- Low Frequency Response : 50 Hz
- High Frequency Response : 200k Hz
- Number of Channels : 2
- Frequency Response : 50 - 200k Hz
- Built In Crossovers : Yes
- RMS Power Range : 125 Watts
- Amplifier Class : A/B
- Fuse Rating : 40 A
Consisting of the most flexible stereo models and potent monoblock models, this amplifiers power is guaranteed to exceed rated power.
Specifications |
Height (inches) |
2-3/8 |
Signal to Noise Ratio |
95 dB |
THD at Rated RMS Power |
1% |
Low-Pass Crossover Frequency |
50-200 Hz |
Depth (inches) |
7-1/8 |
Input Voltage |
14.4v |
Minimum Impedance Bridged |
4 |
RMS Power Output (Watts x Channels) |
30 x 2 |
Bridged Power (Watts x Channels) |
125 x 1 |
Preamp Outputs |
No |
Peak Power Output (Watts x Channels) |
250 x 1 |
Bass Boost Frequency |
40 Hz |
Low-Pass Slope (dB/octave) |
12 dB/octave |
High-Pass Crossover Frequency |
50-200 Hz |
Width (inches) |
8-3/16 |
Power at 2 Ohms (Watts x Channels) |
60 x 2 |
Minimum Impedance Unbridged |
2 |
Best Frequency Response |
10-20000 Hz |
Amplifier Class |
AB |
High-Pass Slope (dB/octave) |
12 dB/octave |
Bass Boost |
0-12 dB |
Fan Cooled |
No |
Fuse Rating |
40 |
- UPC: 713034069669
- Weight: 4.4
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
