Since the beginning, Orion has been all about High Performance Car Audio and Hardcore Attitude… Attitude that is being hammered into the DNA of every piece of industrial-strength Orion Car Audio equipment, and the players that use and abuse it, the bass heads and boulevard bullies who will testify that the baddest car and the loudest system ride on the same chassis – theirs!! SPL competitors, world champions, hot rodders, urban cruisers and the ones that just want to have fun alike are motivated to roll with the bullet proof performance and legendary muscle that is Orion Car Audio.
- Maximum Power : 2000 Watts
- Low Frequency Response : 20 Hz
- High Frequency Response : 20000 Hz
- Number of Channels : 2
- Frequency Response : 20-20000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 100 Watts
- Amplifier Class : D
| Specifications |
| Thermal, DC offset, short protection and under-voltage protection |
3/2/1 Channel operation |
| Subsonic Filter (12 dB at 24 Hz) |
Frequency response: 20-20,000 Hz |
| CEA-2006 compliant amplifier |
Dimensions: 9.3"L x 11.5"W x 2.5"H |
| Silver-plated RCA level inputs |
Silver-plated screw terminals |
| Variable high-pass filter (50-2,000 Hz, 12 dB/octave) |
Variable Low-pass filter (50-2,000 Hz, 12 dB/octave) |
| Power and protection LED Indicators |
Remote gain control |
| Low-level RCA Inputs |
Accepts high-level speaker inputs from an OEM stereo |
| XTR Series 2-Channel Car Amplifier |
RMS Power Rating:4 ohms: 150 watts x 2 chan. / 2 ohms: 250 watts x 2 chan. / Bridged, 4 ohms: 500 watts x 1 chan. |
| Max power output: 1000 watts |
MOSFET Power supply and output stage |
| Gain control continuously adjusts for full power output |
IntelliQ Bass optimization circuit |
| X-Over (crossover) activates the low-pass, FLAT and high-pass crossovers |
X-Over frequency control adjusts the frequency for the high- and low-pass filters |
- UPC: 093207060991
- Weight: 12
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
