What's Included:
- CR2025 Lithium battery (installed)
- Owner's Manual (En/Fr/Sp)
- 6 Pan head ISO-mount screws (M5 x 8mm)
- External microphone w/ sunvisor clip (attached 13' cable terminated by a right-angle male 2.5mm connector)
- Wireless remote control (QXE1044)
- Two-sided tape
- CD receiver (10A fuse)
- Wiring harness
- 6 Flat-head ISO-mount screws (M5 x 9mm)
- Limited Warranty Information (US/CA)
Product Highlights:
- Music file playback on select Android devices through USB input
- MIXTRAX for a DJ-inspired audio/visual experience with compatible devices
- 3-level loudness
- Built-in Bluetooth for hands-free calling and audio streaming
- CD receiver with AM/FM tuner
- FLAC playback from USB drives
- Inputs: front panel auxiliary and USB inputs
- Plays CDs, CD-Rs, and CD-RWs, and USB memory devices (see Details for full capabilities)
- Expandability:
- Pandora and Spotify control with iPhone and Android
- Built in iPod, iPhone, and iPad controls
- Low-pass and high-pass filters
- 13-band equalizer with seven preset tone settings
- Built-in MOSFET amplifier (14 watts RMS CEA-2006/50 peak x 4 channels)
- Variable color illumination with separate control of display and buttons and 10-level dimmer
- Fits double-DIN (4"-tall) dash openings
- Remote control
- ARC app provides smartphone control of receiver
- Advanced Sound Retriever (ASR) for improved sound quality from compressed music files
- Subwoofer level control
- Works with SiriusXM SXV300 satellite radio tuner (supports new Tune Mix feature)
- Outputs: 6-channel preamp outputs (2-volt front, rear, subwoofer)
- Maximum Power : 50 Watts
- Satellite Radio Ready : Yes
- Remote Control : Yes
- RMS Power Output : 14 Watts
- Subwoofer Preamp Outputs : Yes
- Built-in EQ : Yes
- Preamp Voltage : 2 volts
- Bluetooth : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- HD Radio : No
- Preamp Outputs : 6
Control content from the Spotify app on iPhone® and Android™ devices directly from select Pioneer receivers. Pandora is personalized internet radio that is designed to help you discover new music that you'll love mixed in with music that you already know. Play, pause and skip tracks using the Pioneer controls, and with a few button presses easily browse playlists, albums, and radio stations on the go.
Command your radio in a whole new way with the Pioneer ARC App. Control basic functions on your receiver including presets, volume, fast forwards, track back, and more. Browse music files or access music apps directly from the app. Improved Bluetooth! From hands-free calling, wireless audio streaming, simple pairing, and voice recognition, Bluetooth wireless technology has made life in the vehicle much more convenient.
This CD receiver with Bluetooth also includes better call quality reception using the new Wideband Speech Handsfree Profile 1.6. Nearly doubling the bandwidth of the frequency helps bring call quality to similar to FM reception.
Enjoy superior in-vehicle audio performance with enhanced audio functions. Audiophiles and enthusiasts alike can utilize 3 way Network Mode, to attain their idea of the highest level of audio performance. MIXTRAX is an innovative Pioneer technology that creates a nonstop mix of your music library complete with a range of DJ-inspired effects. Drawing from Pioneer’s rich DJ heritage and our passion for music, MIXTRAX delivers a unique DJ infused listening experience to those in the car
Time Alignment, 13-Band EQ and FLAC codec playback*, for precision sound and definition.
See more details below.
| Specifications |
| Audio/video Input |
N/A |
| Android Auto |
No |
| Preamp Voltage |
2 volts |
| Display Color |
Variable |
| Seek/Scan |
Seek |
| Preamp Outputs |
6-channel |
| Full size |
Classic/5Gen |
| Wireless Remote |
Yes |
| Radio Data System |
Yes |
| iPhone |
6S+/6S/6+/6/5S/5C/5/4S/4/3GS/3 |
| Android Control |
Yes |
| AUX Input |
Front |
| FM Sensitivity |
11 dBf |
| Sub Preamp Outputs |
Yes |
| RMS Power Output |
14 watts |
| USB Input |
Front |
| Key Button Color |
Variable |
| Nano |
7/6/5/4/3/2/1 |
| Switchable Rear Preamp Outputs |
No |
| Satellite Radio Ready |
SiriusXM 3.0 |
| Navigation |
N/A |
| European Tuning |
No |
| CarPlay |
No |
| Siri Control |
Yes |
| Memory Card Slot |
USB memory |
| Bluetooth Compatible |
Built-in |
| HD Radio |
No |
| Touch |
6/5/4/3/2/1 |
| CEA-2006 Compliant |
Yes |
| Peak Output |
50 watts |
| RMS Power Bandwidth |
20-20kHz |
| Video Screen |
No |
| EQ Bands |
13 |
| Steering Wheel Control Compatible |
Adapter required |
- UPC: 884938319492
- Weight: 16.2
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
