JL Audio  15w0v2-4

15" 300W SVC 4-Ohm W0 Series Component Car Subwoofer Driver

Item #21991

1 / 1
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.


Huge Saving on Other items:



SPECIFICATIONS


  • Diameter : 15 Inch
  • Low Frequency Response : 20 Hz
  • High Frequency Response : 200 Hz
  • Sensitivity : 88 dB
  • Impedance : 4 Ohm
  • Peak Power Handling : 500 Watts

FEATURES


Recommended Enclosures:
  • Sealed: 1.875 cu ft
  • Ported: 2.75 cu ft
General Details
  • DMA Optimized Motor System
  • Elevated Frame-Cooling
  • Free Air Resonance (Fs): 24.43 Hz
  • Electrical "Q" (Qes): 0.508
  • Mechanical "Q" (Qms): 9.474
  • Total Speaker "Q" (Qts): 0.482
  • Equivalent Compliance (Vas): 5.106 cu. ft. / 144.60 liters
  • One-Way, Linear Excursion (Xmax)*: 0.50 in. / 12.7 mm
  • Reference Efficiency (no): 0.180%
  • Efficiency (1W/1m)**: 88.20 dB SPL
  • Effective Piston Area (Sd): 122.317 in. sq. / 0.0789 m sq.
  • DC Resistance (Re): 3.555 ohm
  • Nominal Impedance (Znom): 4 ohm
  • Thermal Power Handling (Pt): 500W
  • Driver Displacement: 0.109 cu. ft. / 3.09 liters
  • Net Weight: 15.8 lbs. / 7.2 kg
  • UPC:
  • Weight: 0
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • I have two of these bad boys they make your ears hurt if you have the right amp. I have the 500 slash by JL this is a perfect match trust me these subs do not have distortion at all the amp pushes it just right. JL is the best!!! oh and they sound the best in a ported box

    Brandon Krecklow
    3/16/2010

  • I have one of the older versions of this the 15w0v1 and it's awesome. It only handles 300 watts but it makes the most out of every one. hits just as hard as some 1200 watt subs and sounds better than many. Four of these will do the job and hit lows great. They're also great for home audio due to their high efficiency. just take a couple of home tower speakers with 15 inch subs and replace the subs with these a reciever putting out 100 or so watts is plenty to power these things. jl's efficiency never fails to suprise me. Great speakers all around and you can't beat this price. i'm going to order two more!

    Colin
    2/24/2011

  • Installed just one in my S10 Blazer in a sealed down-firing enclosure. Pushing it with a PPI 360.2. SUPER DEEP BASS!!! Volume is retarded. Did not expect this kind of performance out of just one sub with what I consider to be a small amp. Highly recommend this JL 15. I listed to everything from Ice Cube to Deicide. Really deep hard hitting bass when listening to rap. Surprising how tight and responsive the bass drums are when cranking Dying Fetus, Deicide and Five Fingger Death Punch.

    Super-Tim
    6/10/2011
