Rockford Fosgate  P3SD4-8

Punch P3 Slim Series 8" 300W Peak Power Handling 4 Ohms Dual Voice Coil Component Car Subwoofer

Item #35106

Condition:   Brand New

Product Highlights

  • Punch P3 Slim Series
  • 8" Subwoofer
  • 300W Peak Power
  • 4 Ohms Dual Voice Coil
  • Component Car Subwoofer

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:

$169.99

Reg. Price $269.99  Save $100.00
In Stock
In Stock

Only 2 left
Add Extended Warranty
  Free 2-Years Warranty Included!

Starting at $16/mo with . Check your purchasing power

No Credit needed for Learn More

Rockford Fosgate Authorized Dealer

Huge Saving on Other items:


Rockford Fosgate Banner

Rockford Fosgate P3SD4-8 Punch P3 Slim Series 8" 150W RMS (300W Peak Power Handling) 4 Ohms Dual Voice Coil Car Subwoofer


We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • (1) 8" Dual 4-ohm voice coil subwoofer
  • • (1) Trim ring
  • • (8) 1-1/4" Allen head screws
  • • (1) 4mm Allen head bit
  • • Installation/Operation manual (English/ French/ Spanish/ German)
  • • User's Manual
Rockford Fosgate Punch P3 Slim Series

Rockford Fosgate's Punch Stage 3 subwoofers come from a long line of high-performance subs that deliver real deal bass. Now, shallow-mount Punch Stage 3 subwoofers make it easier to get impressive low end in smaller or hard-to-fit vehicles.

Advanced engineering

The P3SD4-8 8" shallow subwoofer hangs with its bigger brethren, thanks to advanced materials and engineering. Rockford uses anodized aluminum for the cone and dust cap making the woofer light and easier to drive, yet rigid enough to maintain its shape under maximum load. The M-Roll Santoprene™ surround also provides excellent excursion for maximum output while being durable enough to last.

Powerful bass for a tight space

A low-profile frame houses the subwoofer, with abundant venting to battle overheating and thermal breakdown. At 2-5/8 inches deep, this sub will fit into places where no bass has gone before — just build a custom enclosure or find a suitable box. The dual 4-ohm voice coils allow you to wire up multiple subs or to coax optimum performance from your amplifier.

  • Diameter : 8 Inch
  • Sensitivity : 82 dB
  • Impedance : 4 Ohm
  • Frequency Response : 38-250 Hz
  • Peak Power Handling : 300 Watts
  • Number of Voice Coils : Dual
  • Suggested Sealed Box Volume : 0.25 Cubic ft.
  • Suggested Ported Box Volume : 0.75 Cubic ft.
  • RMS Power Handling : 150 Watts

Features:

  • M-Roll Santoprene™ surround
  • Diamond cut cast aluminum trim ring with optional grille
  • Dual linear spider with embedded 16 AWG tinsel leads
  • StampCast basket with integrated spider venting
  • Anodized aluminum cone and dustcap
  • Shallow Motor Assembly
  • Optimized for both sealed and vented enclosures
  • 1 Year Warranty



Specifications:

  • Power Handling (Watts RMS)
    • 150 Watts RMS
    • 300 Watts Max
  • Nominal Impedance: Dual 4-Ohms
  • Magnet Weight (oz): 37.5 oz. (1.06 Kg)
  • Voice Coil Diameter: 2" (51.6 mm)
  • SPL (dB @ 1w/1m): 82
  • CEA-2031 Compliant: CEA-2031 Guidelines
  • Cutout Diameter: 7.13 in. (181.0 mm)
  • Qes: 1.05
  • Vas (Liters): 15.8
  • Size: 8"
  • Mounting Depth: 2.66 in. (67.5 mm)
  • Speaker Connector: Dual 10 AWG Compression
  • Shipping Weight: 8.8 Lbs. (3.99 Kg.)
  • Fs (Hz): 39
  • Qts: 0.87
  • Qms: 5
  • Xmax (mm): 8.5
  • Woofer Displacement: 0.040 cu. ft. (1.13 Liters)
  • Re (Ohms): 6.0
  • Le (mH): 1.46
  • Sd (cm2): 220
  • Subwoofer Type: Shallow
  • Voice Coil Type: Dual Voice Coil
  • Sealed Box Volume (Vb): 0.25 cu. ft. (7.0 Liters)
  • Vented Box Volume (Vb): 0.75 cu. ft. (21.2 Liters)
  • UPC: 780687340735
  • Weight: 10
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Placed it in the stock JBL box on my TUndra and it fits fine. Really an easy installation. Sound is much way better than the stock sub, and it also hits harder. Its just 150 watts but its loud enough to make the sound inside your truck boomy.

    Drake
    2/21/2024

  • love how this 8 inch sub sounds so punchy. an awesome sub to have in my 4Runner.

    A. Smith
    6/14/2024
