What's Included:
- Best Frequency Response 5-50k Hz
- Bridged Power (Watts x Channels) 130 x 2
- High-Pass Slope (dB/octave) 12 dB/octave
- Low-Pass Slope (dB/octave) 24 dB/octave
- Speaker Level Inputs Harness
- High-Pass Crossover Frequency 80 Hz
- RMS Power Output (Watts x Channels) 40 x 4
- Bass Boost No
- End;
- Features
- Instruction Manual
- Height (inches) 2-3/16
- Bass Boost Frequency N/A
- Fan Cooled No
- Signal to Noise Ratio 80 dB
- Minimum Impedance Unbridged 2
- Depth (inches) 7-15/16
- Peak Power Output (Watts x Channels) 250 x 2
- Fuse Rating 30
- Specs Sheet
- Input Voltage 14.4v
- Width (inches) 13-1/4
- Power at 2 Ohms (Watts x Channels) 60 x 4
- Minimum Impedance Bridged 4
- THD at Rated RMS Power 1%
- Amplifier Class AB
- Low-Pass Crossover Frequency 50-200 Hz
- Preamp Outputs No
- Maximum Power : 500 Watts
- Low Frequency Response : 5 Hz
- High Frequency Response : 50 Hz
- Number of Channels : 4
- Frequency Response : 5-50 Hz
- Built In Crossovers : Yes
- RMS Power Output : 40x4 Watts
- Channel Separation : Yes
- RMS Power Range : 260 Watts
- Amplifier Class : A/B
- Fuse Rating : 30 A
The amplifier can support a 2-ohm load in stereo; the 2-ohm power output is 60 watts RMS x 4 channels. The amp utilizes a cast aluminum heat sink design to ensure the amplifier stays cool. This amp allows you to turn the amp off in case speaker wire short-circuits, or speaker output contacts ground, and even if the unit malfunctions and DC is sent to speaker output or overheats.
| Other Specifications |
| RMS Power Output (Watts x Channels) |
40 x 4 |
| High-Pass Slope (dB/octave) |
12 dB/octave |
| Power at 2 Ohms (Watts x Channels) |
60 x 4 |
| Fuse Rating |
30 |
| Fan Cooled |
No |
| Height (inches) |
2-3/16 |
| Minimum Impedance Unbridged |
2 |
| Signal to Noise Ratio |
80 dB |
| Amplifier Class |
AB |
| Depth (inches) |
7-15/16 |
| Peak Power Output (Watts x Channels) |
250 x 2 |
| Low-Pass Crossover Frequency |
50-200 Hz |
| Input Voltage |
14.4v |
| Best Frequency Response |
5-50k Hz |
| Low-Pass Slope (dB/octave) |
24 dB/octave |
| High-Pass Crossover Frequency |
80 Hz |
| Bass Boost |
No |
| Bass Boost Frequency |
N/A |
| Speaker Level Inputs |
Harness |
| Preamp Outputs |
No |
| Width (inches) |
13-1/4 |
| Bridged Power (Watts x Channels) |
130 x 2 |
| Minimum Impedance Bridged |
4 |
| THD at Rated RMS Power |
1% |
- UPC: 0019048205575
- Weight: 5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
This amplifier is a good start for my existing stereo system. I'll enjoy til' the
future. I'm getting another 4-chan. amplifier for my ride(car). I liked how the budget(price) is cheap and not too expensive.
