What's Included:
- Four 3/4" #8 self-tapping screws
- Product Information Inside Box
- Owner's Manual
- Mono amplifier
Product Highlights:
- optional remote level control available
- 8-gauge power and ground leads and a 40-amp fuse recommended — wiring and hardware not included with amplifier
- variable low-pass filter (50-200 Hz, 12 dB/octave)
- preamp inputs and outputs
- Class D amp technology
- variable bass boost (0-12 dB at 40 Hz)
- fixed subsonic filter (25 Hz, 24 dB/octave)
- differential-balanced inputs eliminate noise from your vehicle's electrical system
- mono subwoofer amplifier
- 125 watts RMS x 1 at 4 ohms (250 watts RMS x 1 at 2 ohms)
- CEA-2006 compliant
- speaker-level inputs (require speaker wire to RCA adapters)
- no onboard fuses — when installing multiple amps in a system, an additional 40-amp in-line fuse between the distribution block and the amplifier is recommended
- 8-1/8"W x 2-3/8"H x 7-1/8"D
- Maximum Power : 500 Watts
- Low Frequency Response : 200 Hz
- High Frequency Response : 50 Hz
- Number of Channels : 1
- Frequency Response : 50-200 Hz
- RMS Power Range : 250 Watts
- Amplifier Class : D
- Fuse Rating : 40 A
Consisting of the most flexible stereo models and potent monoblock models, this amplifiers power is guaranteed to exceed rated power.
Specifications |
THD at Rated RMS Power |
1% |
Bass Boost |
0-12 dB |
Depth (inches) |
7-1/8 |
Bass Boost Frequency |
40 Hz |
Fuse Rating |
40 |
Signal to Noise Ratio |
95 dB |
Power at 2 Ohms (Watts x Channels) |
250 x 1 |
Low-Pass Crossover Frequency |
50-200 Hz |
Height (inches) |
2-3/8 |
Input Voltage |
14.4v |
Peak Power Output (Watts x Channels) |
500 x 1 |
Low-Pass Slope (dB/octave) |
12 dB/octave |
RMS Power Output (Watts x Channels) |
125 x 1 |
Minimum Impedance Unbridged |
2 |
Best Frequency Response |
25-200 Hz |
Amplifier Class |
D |
Fan Cooled |
No |
Speaker Level Inputs |
RCA |
Preamp Outputs |
1 pair |
Width (inches) |
8-1/8 |
- UPC: 713034069621
- Weight: 4.6
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
