Rockford Fosgate  P1000X5

Punch Series 5-Channel 500W Max Power 4 Ohms Class AB/D Car Amplifier

Item #44623

Condition:   Brand New

Product Highlights

  • Punch Series
  • 5-Channel
  • 500W Max Power
  • 4 Ohms
  • Class AB/D

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:
LIMITED TIME SALE!

Get 10% OFF on this item! Use coupon code OPTNOW

$629.99

Reg. Price $759.99  Save $130.00
In Stock
In Stock

Only 1 left
Add Extended Warranty
  Free 2-Years Warranty Included!

Starting at $57/mo with . Check your purchasing power

No Credit needed for Learn More


Rockford Fosgate Authorized Dealer

Huge Saving on Other items:


Rockford Fosgate Banner

Rockford Fosgate P1000X5 Punch Series Class AB/D 5-Channel Car Amplifier


We are a Rockford Fosgate authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •5-Channel amplifier
  • •(4) 1-1/2" Self-tapping screws
  • •2.5mm Allen wrench
  • •Quick setup instructions
  • •Certificate of Performance
  • •Owner's Manual
Offers a Higher Level of Efficiency

The P1000X5 1,000 Watt full-range 5-channel is the one-and-only amplifier you will need to run your entire system. Run dash speakers off the front channels, run back speakers off the rear channels and run subwoofer(s) off the 5th channel! Known world-wide for brute power, this amplifier offers a higher level of efficiency along with a tri-stage protection that covers thermal, over-current and short circuits.

C.L.E.A.N. Level Setting System

C.L.E.A.N. (Calibrated Level Eliminates Audible Noise) is our patented circuit with in/out clip LEDs to help match a source to amp and optimize output. Delivers more bass where you want it most by allowing up to 18dB of boost adjustment at 45Hz. The RCA inputs of this amp can accept both Hi or Low level audio signals without the need of a signal converter.

Dynamic Thermal Management System

Rockford Fosgate's Dynamic Thermal Management system uses forced air to dissipate heat evenly across the amp and out through the high-mass heatsink, efficiently drawing heat away from vital internal parts. Their proprietary MEHSA cooling process maximizes the heat transfer from the MOSFET devices to the heatsink, allowing the heat to escape more readily, so the transistors stay cooler and work better.



  • Maximum Power : 500 Watts
  • Low Frequency Response : 50-250 Hz
  • High Frequency Response : 50-250 Hz
  • Number of Channels : 5
  • Frequency Response : 20-20000 Hz
  • Built In Crossovers : Yes
  • Channel Separation : Yes
  • RMS Power Range : 1000 Watts
  • Amplifier Class : AB/D
  • Fuse Rating : 150 A

Features:

  • Featured in our article: Best multi-channel car amplifiers for 2023
  • 5-channel car amplifier
  • 75 watts RMS x 4 + 150 watts RMS x 1 at 4 ohms
  • 125 watts RMS x 4 + 300 watts RMS x 1 at 2 ohms
  • 250 watts RMS x 2 bridged at 4 ohms + 500 watts RMS at 1 ohm
  • CEA-2006 compliant
  • variable high- and low-pass filters (50-250 Hz, 12 dB/octave)
  • variable PEQ2 bass/treble boost (0-18 dB at 45 Hz and 0-14 dB at 12.5K Hz)
  • switchable subsonic filter (28 Hz, 12 dB/octave) on subwoofer channel
  • C.L.E.A.N. gain setup system includes clip lights and link to Rockford Fosgate's setup tones
  • Class-BD amplifier design
  • frequency response: 20-20K Hz
  • Dynamic Thermal Management and MEHSA MOSFET cooling systems
  • MOSFET power and output stages
  • preamp and speaker-level inputs (speaker-level inputs require a speaker wire to RCA adapter)
  • signal-sensing turn-on with speaker-level inputs eliminate need for remote turn-on lead
  • optional PLC2 wired remote level control with clip light available
  • 4-gauge power and ground leads and an 150-amp fuse recommended — wiring and hardware not included with amplifier
  • no onboard fuses — when installing multiple amps in a system, an additional 150-amp in-line fuse between the distribution block and the amplifier is recommended
  • 15-1/8"W x 2-7/16"H x 8-13/16"D
  • warranty: 1 year



Specifications:

  • RMS Power Output (Watts x Channels): 75 x 4 , 300 x 1
  • Peak Power Output (Watts x Channels): N/A
  • Power at 2 Ohms (Watts x Channels): 125 x 4
  • Bridged Power (Watts x Channels): 250 x 2
  • Minimum Impedance Bridged: 4
  • Minimum Impedance Unbridged: 2
  • Minimum Impedance: 2
  • Best Frequency Response: 20-20k Hz
  • THD at Rated RMS Power: 1%
  • Signal to Noise Ratio: 85 dB
  • Input Voltage: 14.4v
  • Amplifier Class: AB/D
  • Low-Pass Crossover Frequency: 50-250 Hz
  • Low-Pass Slope (dB/octave): 12 dB/octave
  • High-Pass Crossover Frequency: 50-250 Hz
  • High-Pass Slope (dB/octave): 12 dB/octave
  • Bass Boost: 0-18 dB
  • Bass Boost Frequency: 45 Hz
  • Fan Cooled: No
  • Fuse Rating: 150
  • Speaker Level Inputs: Yes
  • Preamp Outputs: No
  • Width (inches): 15-1/8
  • Height (inches): 2-7/16
  • Depth (inches): 8-13/16
  • Parts Warranty: 1 Year
  • Labor Warranty: 1 Year



  • UPC: 780687342180
  • Weight: 16
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Just recently installed one a month ago on my Accord and I’m really liking what I’m hearing. Great product from RF! Clean and powerful sound! Totally would recommend this for those looking for a 5ch amp!

    Sebastian
    2/14/2024
