Power Acoustik BAMF-124 BAMF Series 12" 3500W Peak Power Handling 4 Ohm, Dual Voice Coil Component Car Subwoofer
We are a Power Acoustik authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 12" 3500W 4 Ohms, Dual Voice Coil Component Car Subwoofer
- • Owner's Manual
Immersive Audio Experience
Experience powerful bass performance with the BAMF-124 subwoofer, boasting an impressive max power handling of 3,500 Watts and RMS power handling of 1,750 Watts. Featuring a dual 4Ω voice coil configuration and a massive 272 oz motor volume, this subwoofer delivers deep, resonant lows with an efficiency of 84.60 dB. With a sleek mounting depth of 6.75 inches and optimized enclosure volumes of 1.00 cubic feet for sealed and 2.00 cubic feet for ported setups, immerse yourself in immersive audio experiences that redefine your car audio system's capabilities.
High-Temperature Tolerance
Experience enhanced bass performance with our subwoofer's overcompensated motor structure and 12mm T-yoke, ensuring improved low-frequency dynamics. With a vented T-yoke and frame design, heat build-up is minimized, while a non-magnetic, non-resonant die-cast aluminum frame ensures durability. Enjoy increased power handling with a 3” 4-layer voice coil featuring direct connect wire, supported by high-temperature tolerance adhesives for prolonged durability.
Smoother Performance
Our subwoofer features UV and chemical protection for its non-transfer spruce pulp cone, along with stitched and glued surround/cone joints, extended excursion polyether foam surround with UV protection, dual poly-cotton suspension for smoother performance, stitched voice coil leads to prevent damage, and convenient installation with an included 1-piece gasket/trim ring featuring concealed mounting holes.
- Diameter : 12 Inch
- Sensitivity : 84.6 dB
- Impedance : 4 Ohm
- Peak Power Handling : 3500 Watts
- Shallow Mount : No Inch
- Number of Voice Coils : Dual
- Suggested Sealed Box Volume : 1 Cubic ft.
- Suggested Ported Box Volume : 2 Cubic ft.
- Mounting Depth : 6.75 Inches
- RMS Power Handling : 1750 Watts
Features:
- Enhanced magnetic strength with overcompensated motor structure
- Improved low-frequency dynamics with 12mm T-yoke and top plate
- Reduced voice coil heat build-up through vented T-yoke and frame design
- Non-magnetic, non-resonant die-cast aluminum frame construction
- Increased power handling with a 3” 4-layer voice coil featuring direct connect wire
- High-temperature tolerance adhesives resist thermal failure for prolonged durability
- UV and chemical protection for the non-transfer spruce pulp cone
- Strongest bonding ensured with stitched and glued surround/cone joints
- Extended excursion polyether foam surround with UV protection for longevity
- Dual poly-cotton suspension dampens violent accelerations for smoother performance
- Stitched voice coil leads prevent potential damage over time
- Convenient installation with included 1-piece gasket/trim ring with concealed mounting holes
Specifications:
- Max Power Handling: 3,500 Watts
- RMS Power Handling: 1,750 Watts
- Efficiency (1w/1m): 84.60 dB
- Voice Coil Configuration: Dual 4Ω, 3" each
- Motor Volume: 272 oz
- Mounting Depth: 6.75"
- Optimum Sealed Enclosure Volume: 1.00 cubic feet
- Optimum Ported Enclosure Volume: 2.00 cubic feet
Recommended Enclosure Specifications:
- Recommended Enclosure Type: Ported / Vented, Sealed
- Minimum Sealed Box Volume: 0.75 cubic feet
- Optimum Sealed Box Volume: 1 cubic feet
- Maximum Sealed Box Volume: 1.25 cubic feet
- Minimum Ported Box Volume: 1.375 cubic feet
- Optimum Ported Box Volume: 2 cubic feet
- Maximum Ported Box Volume: 2.25 cubic feet
- Top-Mount Depth (Mounting Depth): 6.75"
- Cutout Diameter: 11.25"
- Shallow Mount Installation: No
Electromechanical Parameters:
- Free-Air Resonance (Fs): 36.3 Hz
- Equivalent Compliance (Vas): 0.83 liters
- Total Speaker Q Value (Qts): 0.57
- Electrical Q Value (Qes): 0.66
- Electrical Resistance of Voice Coil (Re): 7.2 ohms
- Mechanical Q Value (Qms): 3.82
- UPC: 709483055773
- Weight: 24
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
