- Maximum Power : 1500 Watts
- Low Frequency Response : 35-160 Hz
- Number of Channels : 1
- Frequency Response : 9-50000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 1125x1 Watts
- Channel Separation : No
- Amplifier Class : A/B
- Fuse Rating : 30x1 A
Features:
- Monoblock Class A/B, MOSFET Power Supply
- High and Low Level Inputs
- Variable Low Pass Crossover, Switchable Bass Boost
- Include Remote Subwoofer Control
- Blue Illuminated Planet Audio Logo and End Panel Strips
- Dimensions: 9.96" L x 7" W x 2.39" H
General Specs
- Channel Configuration: 1 Channel
- Power Supply Type: MOSFET Power Supply
- AMP Topology: Monoblock Class A/B
Performance Specs
- Total Power Output: 1500 Watts
- Peak Power @ 2 ohms: 1500 Watts x 1
- RMS Power @ 4 ohms: 563 Watts x 1
- Speaker Impedance: 2 to 8 ohms
- S/N RATIO (A-WEIGHTED): 103 dB
- Frequency Response: 9 Hz to 50 kHz ±1 dB
Connections, Controls, and Processing
- RCA Inputs: 2 Channel
- High Level Inputs: Yes
- Low Pass Filter: 50 Hz to 250 Hz
- Bass Boos: Switchable 0 or 18 dB
- Subwoofer Level Control: Yes
- Input Sensitivity Switch: Yes
- THERMAL/OVERLOAD/SHORT PROTECTION: Yes
Measurement
- Width: 7"
- Height: 2.39"
- Length: 9.96"
- UPC:
- Weight: 5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
