Hertz  HCP 2X

Compact Power Series200Wx2 RMS 2 Ohms Class A/B 2-Channel High Power Stereo Amplifier

Item #54235

Condition:   Brand New

0
❮ ❯
1 / 3
Product Highlights
  • Compact Power Series
  • 200W x2 RMS
  • 2 Ohms
  • Class A/B
  • 2-Channel Stereo Amplifier
  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
0 Review

$299.99

Reg. Price $325.00  Save $25.01
Special Order Item

Estimated shipping time is 7-10 days. Risk Free

Add Extended Warranty
  Free 2-Years Warranty Included!

No Credit needed for . Learn More

Add to Cart
 Alert me on price change
 Fit Guide. Check if it will fit your car.
We Price Match! Call Us! 310-526-8635
Hertz Authorized Dealer

Huge Saving on Other items:

PAC Banner

Hertz HCP 2X 200Wx2 RMS @ 2 ohms, Class A/B 2-Channel High Power Stereo Amplifier

Alpine Banner for OCS

We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •800W Car Subwoofer Amplifier
  • •Owner's Manual
Brand New Stereo Car Audio Amplifier

HCP 2X is a brand new stereo car audio amplifier, 800W amplifier, designed to expand or modify with maximum easiness the factory system: featuring pre-amplified (Pre-In) inputs as well as high-level (Speaker-In) inputs, for connection with any head units. All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier. With HCP 2X high power systems can be realized: settable both in mono, to drive the subwoofer, and together with another amplifier, for more complex systems; it also features a Bass Boost filters (0 ÷ 12 dB) to enhance low frequencies.

  • Low Frequency Response : 50-3200 Hz
  • High Frequency Response : 50-3200 Hz
  • Number of Channels : 2
  • Frequency Response : 10-65000 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 200x2 Watts
  • Amplifier Class : A/B
  • Fuse Rating : 20x1 A

Features:

  • Compact design built from extruded aluminum heatsink with the top side ensuring effective transfer of the heat.
  • Special balanced high-noise rejection input circuitry on the Pre-In or Speaker-In inputs.
  • Speaker-In (for OEM head units) and RCA-In (for Aftermarket head units) inputs.
  • Selectable ART, Automatic Remote Turn-On/Off function, automatically turns on and off the amplifier when the OEM radio turns on and off (can be enabled/disabled, with only Speaker-In inputs).
  • Power supply featuring multiple winding transformer, Low-ESR 105°C capacitors, AB-Class 2 ohm stable output stage.
  • Pre-outs, also available when using Speaker-In level inputs.
  • Mono operation mode (selectable) to drive a subwoofer or, in combination with a second amplifier, to create a powerful dual-mono system.
  • Bass Boost (50 Hz) adjustable at 0 dB, 3 dB or 6 dB via selector, for more punch from the subwoofer.
  • Hi-Pass, Lo-Pass and Full-range crossover filters with 12 dB/Oct. slope and variable frequency (50 Hz - 3200 Hz), both selectable, with a greater application versatility for the design of active systems.



Specifications:

  • Channel mode: 2-1
  • Output Power (RMS) @ 14.4 VDC
    • 2 Ch: 120 W x 2 (4ohms)
    • 2 Ch: 200 W x 2 (2ohms)
    • 1 Ch: 400 W x 1 (4ohms)
  • Filters
    • Bypass: ---
    • Hi-Pass: 50 ÷ 3200 Hz @ 12 dB/Oct.
    • Lo-Pass: 50 ÷ 3200 Hz @ 12 dB/Oct.
    • Band-Pass: ---
    • Subsonic: ---
  • Distortion - THD (100Hz @ 4 ohms): 0.03 %
  • S/N Ratio (A weighted @ 1V): 105 dB
  • Damping factor (100Hz @ 4 ohms): 300
  • Size W x D x H mm (in.): 315 x 190 x 50 (12.40 x 7.48 x 1.97)
  • UPC: 8018823114967
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.

Do you own this product?

Write a review!
  • Low Frequency Response : 50-3200 Hz
  • High Frequency Response : 50-3200 Hz
  • Number of Channels : 2
  • Frequency Response : 10-65000 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 200x2 Watts
  • Amplifier Class : A/B
  • Fuse Rating : 20x1 A

Features:

  • Compact design built from extruded aluminum heatsink with the top side ensuring effective transfer of the heat.
  • Special balanced high-noise rejection input circuitry on the Pre-In or Speaker-In inputs.
  • Speaker-In (for OEM head units) and RCA-In (for Aftermarket head units) inputs.
  • Selectable ART, Automatic Remote Turn-On/Off function, automatically turns on and off the amplifier when the OEM radio turns on and off (can be enabled/disabled, with only Speaker-In inputs).
  • Power supply featuring multiple winding transformer, Low-ESR 105°C capacitors, AB-Class 2 ohm stable output stage.
  • Pre-outs, also available when using Speaker-In level inputs.
  • Mono operation mode (selectable) to drive a subwoofer or, in combination with a second amplifier, to create a powerful dual-mono system.
  • Bass Boost (50 Hz) adjustable at 0 dB, 3 dB or 6 dB via selector, for more punch from the subwoofer.
  • Hi-Pass, Lo-Pass and Full-range crossover filters with 12 dB/Oct. slope and variable frequency (50 Hz - 3200 Hz), both selectable, with a greater application versatility for the design of active systems.



Specifications:

  • Channel mode: 2-1
  • Output Power (RMS) @ 14.4 VDC
    • 2 Ch: 120 W x 2 (4ohms)
    • 2 Ch: 200 W x 2 (2ohms)
    • 1 Ch: 400 W x 1 (4ohms)
  • Filters
    • Bypass: ---
    • Hi-Pass: 50 ÷ 3200 Hz @ 12 dB/Oct.
    • Lo-Pass: 50 ÷ 3200 Hz @ 12 dB/Oct.
    • Band-Pass: ---
    • Subsonic: ---
  • Distortion - THD (100Hz @ 4 ohms): 0.03 %
  • S/N Ratio (A weighted @ 1V): 105 dB
  • Damping factor (100Hz @ 4 ohms): 300
  • Size W x D x H mm (in.): 315 x 190 x 50 (12.40 x 7.48 x 1.97)
  • UPC: 8018823114967
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
