Audison APX5 PRIMA Series 5" 150W Peak Power Handling, 4-Ohms, 2-Way,Coaxial Speakers (Pair)
We are a Audison authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • 2* Speakers
- • 2* Tweeters
- • 2* Woofers
- • Pair of 165mm speaker protective grilles
- • Owner's Manual
Concentric Coaxial Tweeter
APX 5 features a concentric coaxial tweeter: with one single point of sound emission it is possible to obtain a consistent in-phase response, with consequent reconstruction of the acoustic scene comparable to a system of separate woofer + tweeter. The 5″ cones surround features the exclusive shallow “Triple Wave” profile, for maximum excursion linearity.
Coaxial Speaker System with Tweeter Fusion for Seamless Sound
The concentric coaxial tweeter is integrated into the woofer, emitting sound from a single point for consistent phase response and accurate sound stage recreation comparable to a component system. The tweeter includes a specially designed acoustic lens for a linear frequency response, even in off-axis placements common in indoor installations. Featuring a 32 mm pure copper voice coil for high power handling and precise low-frequency control, the system has an optimized overall mounting depth for seamless OEM integration. The water-repellent paper cone is developed with Finite Element Method simulation technology and Klippel Scan Vibrometer optimization. With a TPU suspension boasting a unique "triple wave" profile for maximum excursion linearity, a compact basket with abrasion-resistant coating, and a high-current fast-on terminal, this speaker system offers flexibility, durability, and quick connections. Developed with the KLIPPEL suite, it combines advanced features for optimal audio performance.
- Diameter : 5.25 Inch
- Sensitivity : 93 dB
- Impedance : 4 Ohm
- Frequency Response : 70-23000 Hz
- Peak Power Handling : 150 Watts
- Design : 2 Way
- RMS Power Handling : 50 Watts
Product Highlights:
- Concentric Coaxial Tweeter: tweeter is mounted within the woofer with one single point of emission providing consistent phase response, with an accurate recreation of the sound stage comparable to that of a component system.
- Tweeter features an acoustic lens specifically designed to ensure an extremely linear frequency response, even in off-axis placement, typical of in-door installations.
- 32 mm pure copper voice coil, for high power handling and outstanding low frequency control
- Overall mounting depth optimized for OEM Integration thanks to the concentric tweeter and the low profile basket
- Water-repellent treated paper cone, featuring a profile developed with FEM (Finite Element Method) simulation technology and optimized with the Klippel Scan Vibrometer.
- TPU (Thermoplastic Polyurethane) surround, featuring the exclusive shallow “Triple Wave” profile, for maximum excursion linearity.
- Compact basket, protected by abrasion-resistant and scratchproof coating, the motor affixed with damping epoxy adhesive.
- High current fast-on terminal with double contact on positive and negative poles for high flexibility and quick connection. The terminal features a temperature resistant plastic cover, protecting it against accidental short circuits.
- Developed with the KLIPPEL suite.
Specifications:
- Comp: Two way coaxial
- Size:
- Woofer 130 mm (5″)
- Tweeter diaphragm 24 mm (0.9″)
- Power Handling:
- 50 W Continuous Power
- 150 W Peak Power
- Impedance: 4 ohms
- Frequency Response: 70 ÷ 23k Hz
- Sensitivity: 93 dB/Spl
- Magnet: High density flux ferrite
- Dome: Water-repellent pressed paper
- UPC: 8018823111690
- Weight: 7
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
**Speakers purchased and installed by an authorized Audison dealer will have a three (3) year limited warranty from the original date of purchase.
