Keep your vehicle OFF and your amplifiers ON with the BP-PS100. The BP-PS100 AC to DC power supply housed in a rugged "Blade BP" styled heat sink can push out over 100 Amps of DC current with an adjustable regulated output control at up to 16V. The BP PS100 uses twin internal thermal cooling fans with a remote mount LCD voltage display and can protect itself with an automatic overload shut off system. The PS100 can be linked with up to four additional units to produce over 400 amps of DC voltage by converting 110-130V AC household power into adjustable 1-~16V DC power. The BP-PS100 is great for show room displays, car show events, demos and test benches.
Features:
- Adjustable Regulated Output Voltage 10~16V
- Up to 100 Amp Output Current
- Cooling Fans
- Thermal/ Current Overload Shut Off Protection
- Combo Output Connectors Act as Both Binding Posts & Banana Plug Terminals
- Remote Mount LCD Voltage Display
- Link Up to 4 Units for Up to 400 Amps of Current
- The BP-PS100 Converts standard 110-130V AC Household Power to an Adjustable 10~16V DC Power and Supplies Up to 100 Amps Continuously
- The BP-PS100 is a Multi-Purpose Unit Great for Show Room Displays, Car Show Events, Demos and Test Benches
Specifications:
- Design: Switching Type
- Input Voltage: 120V AC ± 10%
- Input Frequency: 60Hz
- Adjustable Output: 10V~16V DC ± 0.5 Volts
- Output Current: 100 Amps DC Continuous (Maximum)
- Line Regulation: Less Than ± 5%
- Load Regulation: Less Than ± 5%
- Efficiency: More Than 85%
- Overload Protection: More Than 100 Amps
- Output Ripple: 150MV RMS
- Protection Temperature: 75°C
- Power Switch: 15A/ 250V AC
- Dimension: 2.2"H x 7.5"W x 11.9"L
For more Information:
BP-PS100 Owner's Manual
- UPC: 623169631337
- Weight: 9
