The EVO X Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system.
The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.
- Maximum Power : 2400 Watts
- Low Frequency Response : 45-850 Hz
- High Frequency Response : 45-850 Hz
- Number of Channels : 4
- Frequency Response : 5-25000 Hz
- Built In Crossovers : Yes
- RMS Power Output : 396x4 Watts
- Channel Separation : Yes
- Fuse Rating : 120 A
Specifications:
- Power @ 4Ohms: 4 X 262 WRMS
- Power @ 2Ohms: 4 X 396 WRMS
- Power @ 1Ohm: 4 X 600 WRMS
- Bridge Power @ 4?: 2 X 792 WRMS
- Bridge Power @ 2?: 2 X 1200 WRMS
- Operating Voltage: 8V – 16V
- Current Draw (Music): 104 A
- Current Draw (Max): 208 A
- Recommended Fuse (Music): 120 A
- Total Efficiency: 80%
- Damping Factor: 200
- Frequency Response (-3dB): 5Hz – 25kHz
- SNR: 90dB
- Crossover HPF: 45Hz – 850Hz
- Crossover LPF: 45Hz – 850Hz
- THD + N (10% Rated Power): 0.1%
- Product Dimensions: 8.9 x 5.4 x 2.2 in
- Product Dimensions: 22.7 x 13.6 x 5.5 cm
- UPC:
- Weight: 6
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
