Infinity INFDSP6840 DSP Series 480W RMS (1000W Peak Power Handling) Class-D 8-Channel Amplifier with Digital Signal Processing (DSP)
We are an authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • DSP Amplifier
- • Wiring Harness
- • USB Drive with Tuning Software
- • USB Tuning Cable
- • Wired Remote Level Bass Control
- • Mounting Hardware
- • (6) High-Level Input Adapters
- • Spare Fuse
- • (4) Wire Ties
- • (2) Infinity Stickers
- • Quick Start Guide
Powerhouse Audio Amplifier
The Infinity INFDSP6840 is an 8-channel Class D amplifier, offering 480 watts of power. It has a 2-ohm stable design, LED Power/Protect light, and a wired bass level remote control for easy customization. With signal sensing remote turn-on and speaker-level inputs, it's perfect for enhancing your car audio system.
Features Led Power/protect Light Indicators
The DSP Series Class D 2 ohms Stable 8-Channel Amplifier offers versatile performance with an RMS power rating of 40 watts x 8 channels at 4 ohms and 60 watts x 8 channels at 2 ohms, providing a total power output of 480 watts. It features LED Power/Protect Light indicators for easy monitoring, includes a wired bass level remote control for convenient adjustment, and supports speaker-level (high-level) inputs for seamless integration into various audio systems. Additionally, its signal sensing remote turn-on feature enhances user experience by automatically activating the amplifier when a signal is detected.
- Maximum Power : 1000 Watts
- Number of Channels : 8
- Frequency Response : 10-22000 Hz
- Amplifier Class : D
- Fuse Rating : 40 A
Features and Benefits
-
Compact Class D Amplifier with DSP Control: The Infinity DSP Amplifier is designed to fit in tight spaces while providing all the tools needed to create a professional sound system.
-
Complete Audio System Solution: Whether you're starting a new system or upgrading an existing one, this amplifier has everything required, including the option to act as a line driver for future power upgrades.
-
User-Friendly Tuning Interface: The amplifier features an intuitive Windows PC interface that includes variable crossover control, selectable 0-to-48dB slopes, 31-band parametric or graphic EQ, time delay (0.2ms), output clipping indicator, input/output channel summing, output channel gain, master volume control, and the ability to save up to 10 presets.
-
Versatile Connectivity: Equipped with balanced differential inputs, the amplifier supports RCA or speaker-level inputs for maximum flexibility. It includes screw-on RCA-to-bare wire adapters and labeled wire connections for easy installation.
-
Convenient Bass Control: Adjust low-frequency output directly from the driver's seat using the wired remote control with -30dB to +6dB adjustment.
-
Durable Build: The amplifier is built to withstand harsh conditions with a conformal-coated PCB, ensuring reliable performance in any environment.
-
Harman Standard Reliability Testing: Infinity's reputation for durability and high performance is backed by rigorous testing, ensuring long-lasting quality and reliability.
-
Sleek Industrial Design: The amplifier's modern design, featuring a smooth curve, angular end cap, and the iconic Infinity logo, blends style with functionality, making it an attractive addition to any setup.
What's in the Box
- DSP Amplifier
- Wiring Harness
- USB Drive with Tuning Software
- USB Tuning Cable
- Wired Remote Level Bass Control
- Mounting Hardware
- 6x High-Level Input Adapters
- Spare Fuse
- 4x Wire Ties
- 2x Infinity Stickers
- Quick Start Guide
Technical Specifications
- Max Power: 1000W peak
- RMS Power Output @ 2Ω: 60W x 8 channels, <1% THD+N
- RMS Power Output @ 4Ω: 40W x 8 channels, <1% THD+N
- Crossover Settings: Variable high-pass, low-pass, band-pass filters with adjustable 0-to-48dB slopes
- EQ Adjustment: Selectable between Parametric or Graphic EQ
- Turn-On Modes: Selectable 12V, Signal Sense, or DC Offset, with 12V remote output
- Frequency Response: 10Hz to 22kHz at -3dB
- Signal-to-Noise Ratio: >90dB at 4Ω
- Subwoofer Level Control: Adjustable from -30dB to +6dB
- Fuse Rating: 40A
- Operating Voltage: 8V to 16V
- UPC: 0 50036 39539 7
- Weight: 4
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
