Onlinecarstereo Exclusive Bundle
This exclusive package is brought to you by Onlinecarstereo. We have put together this bundle to kickstart your vehicle to the path of excellent car audio.
Boss Elite BE920WCPA 2-DIN 7" Digital Media Receiver + Metra Electronics 99-5846B Ford F-150 2013-2014 (With factory 4.2in screen) -TurboTouch + Metra Electronics 40-CR10 Factory Antenna to Aftermarket Radio Adapter for Chrysler/Dodge/Ford/GM 2006/Jeep 2002-Up + Metra Electronics 70-5520 OEM Deck Harness + Axxess AXVI-5520 Data Interface for Ford 2007-Up + Axxess AXSWC Universal Steering Wheel Control Interface for 2015-Present Ford Mustang with 8" Oem Screen
We are an authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • BE920WCPA Digital media receiver (15A fuse)
- • BE920WCPA Trim-ring (pre-installed)
- • BE920WCPA Wiring harness
- • BE920WCPA WiFi antenna (pre-installed)
- • BE920WCPA GPS antenna (attached 59" cable terminated by SMB connector)
- • BE920WCPA Microphone w/ integrated bracket (attached 9.5' cable terminated by a stereo 3.5mm connector)
- • BE920WCPA 2 Side-brackets
- • BE920WCPA 8 ISO-screws
- • BE920WCPA Two-sided tape
- • BE920WCPA Warranty/Registration Card
- • BE920WCPA User's Manual
- • 99-5846B Dash Kit
- • 99-5846B Owner's Manual
- • 40-CR10 Antenna Adapter
- • 40-CR10 Owner's Manual
- • 70-5520 Harness
- • 70-5520 Owner's Manual
- • AXVI-5520 Data Interface Harness
- • AXVI-5520 Owner's Manual
- • AXSWC Interface
- • AXSWC Harness (12-pin harness with male 3.5mm jack)
- • AXSWC 3.5mm adapter
Apple CarPlay 4
It features Apple CarPlay, the smarter, safer and more fun way to use your iPhone® in the car. Apple CarPlay gives iPhone users an incredibly intuitive way to make calls, use Maps, listen to music, and verbally send and listen to messages with just a word or a touch. Apple CarPlay requires iPhone 5 or newer with the latest version of iOS.
Android Auto
It also features Android Auto, which extends the Android platform into the car in a way that’s purpose-built for driving. Android Auto automatically brings you useful information and organizes it into simple cards that appear just when they’re needed. It’s designed to minimize distraction so you can stay focused on the road ahead.
Retained Accessory Power
ISO DIN radio provision with pocket, ISO DD INradio provision, Integrated controls for info center, Touchscreen display for climate and personalization features, Center panel painted silver with tan or black trim, included interface for audio – climate and steering wheel functions, Painted tan, Provides accessory power (12-volt 10-amp), Retains R.A.P. (retained accessory power), Provides NAV outputs (parking brake – reverse – speed sense), RetainsSYNC, Retains the factory AUX-IN jack, Provides an aftermarket backup camera input, Can be used in both amplified and non-amplified models, Retains audio controls on the steering wheel, Retains balance and fade, Micro BUSB updatable.
Simple Yet Necessary Cable
If you are replacing the radio in your vehicle, this antenna cable adapter ensures that you can continue to use your factory antenna. It is a simple yet necessary cable that adapts the vehicle’s original antenna cable to plug into an aftermarket radio with a male Motorola™ connector on one end and a snap-lock female antenna connector on the other.
Designed to Simplify the Installation of an Aftermarket Car Stereo
The Metra Electronics 70-5520 is a wiring harness designed to simplify the installation of an aftermarket car stereo in select Ford vehicles. The harness connects to the factory wiring and allows the user to avoid cutting and splicing the original wires, which can be time-consuming and potentially damaging.
The 70-5520 harness is compatible with many Ford models from 2003 to 2010, including the Ford Expedition, Explorer, F-150, and Mustang. It features color-coded wires that match the aftermarket stereo's wiring, making it easy to connect the two systems without confusion.
The harness also has an optional built-in amplifier retention circuit sold separately, allowing the user to retain the vehicle's factory amplifier when upgrading to an aftermarket stereo. This is particularly useful for those who want to maintain the original sound quality of their vehicle's audio system.
Data Interface
With this, it allows the user to connect digital media sources such as iPods, iPhones, and USB drives to the car audio system. It is typically used to stream music, access navigation applications, and control certain settings in the car audio system.
Steering Wheel Control Harness
This wiring harness allows you to connect various electrical components of a car to the steering wheel. It is typically used to connect a hands-free device such as a Bluetooth headset, or a car stereo system, to the steering wheel. This harness is designed to provide a secure connection that ensures the electrical components are securely connected to the steering wheel.
- Satellite Radio Ready : No
- DIN : 2
- Vehicle Make : Ford
Boss Elite BE920WCPA 2-DIN 7" Digital Media Receiver
Features:
- 80 Watts x 4 max power
- RBDS Tuner, balance/fader/bass/treble and preset built-in EQ
- Mech-less (no CD or DVD player)
- Plays Bluetooth/USB, MP3, WMA, JPEG, FLAC, OGG, APE, FM/AM, digital media from smart phones
- Compatible with audio out from smart phones and MP3 players
- USB, Aux, steering wheel control input
- Front, rear & sub pre-amp outputs
- USB charging, multi-color Illumination options
- Single-DIN installation with floating oversized touch screen
- Bluetooth hands free; make and receive calls, Bluetooth audio streaming
- Play and control music and apps such as Spotify/Pandora wirelessly
Specifications:
- USB Port: Rear Cable
- SD Port: Front panel
- iPod Input: Yes
- A/V Input: Rear
- Front, Rear & Sub
- Total Power Output: 340 Watts (Watts x Ch)
- Full iPod Control: Yes
- Steering Wheel Control (*Interface not included): Yes
- Screen Size: 7"
- Touchscreen: Yes
- Resolution: 800 x 480
- Switchable Tuner Frequencies: USA
- Tuner Preset: 10 FM / AM
- Selectable Preset EQ: Yes
- ID3-Tag Information: Yes
- Clock Display: Yes
- Chassis Type: Double-DIN
- Apple CarPlay and Android Auto: Seamlessly integrates smartphone with car’s display and controls for safer usage on the road.
- Features include: phone calls, music access, messaging, directions, and more while staying focused on driving.
Metra Electronics 99-5846B Ford F-150 2013-2014 (With factory 4.2in screen) -TurboTouch
Features:
- ISO DIN radio provision with pocket
- ISO DDIN radio provision
- Touchscreen display for climate and personalization features
- Integrated hazard button and passenger airbag light
- Radio can be mounted up top or at bottom
- Painted matte black
Axxess interface included:
- Provides accessory power (12-volt 10-amp)
- Retains R.A.P. (retained accessory power)
- Provides NAV outputs (parking brake, reverse, speed sense)
- Retains audio controls on the steering wheel
- Retains SYNC
- Retains the factory backup camera
- Retains balance and fade
- Micro B USB updatable
Wiring and Antenna Connections:
Axxess interface built into touchscreen
Metra Electronics 40-CR10 Factory Antenna to Aftermarket Radio Adapter for Chrysler/Dodge/Ford/GM 2006/Jeep 2002-Up
Features:
- Adapts aftermarket radio to factory antenna connection
- Antenna adapter cable
- Used to adapt the vehicle’s antenna cable to use with an aftermarket radio
- Male Motorola™ connector on one end
- Snap-lock female antenna connector on the other end
- Enter your vehicle model to see if this is compatible with your vehicle
Metra Electronics 70-5520 OEM Deck Harness
Allows installation of an aftermarket radio using the existing factory wiring and connectors. No cutting of factory wiring is needed.
- Wiring harness for fast and easy radio installation
- Plugs into the car's original radio connectors on one side
- To retain the factory AV/DVD, use 70-5520AV in addition
- Color-coded wires on the other side are connected to the aftermarket radio
- No wire cutting needed for factory radio connectors
- 24-way plug provides electrical power to the radio and speaker connection
- A tech support number is available for installation help 7 days a week
- Enter your vehicle model to see if this is compatible with your vehicle
Axxess AXVI-5520 Data Interface for Ford 2007-Up
Features:
- Provides accessory power (12-volt 10-amp)
- Retains R.A.P. (Retained Accessory Power)
- Used in non-amplified systems or when replacing amplified systems
- Provides NAV outputs (parking brake, reverse and speed sense)
- Pre-wired AXSWC harness (AXSWC sold separately)
- High-level speaker input
- Micro-B USB updatable
Vehicle Applications:
- Ford
- Econoline 2009-Up
- Edge 2007-2010
- Escape 2008-2012
- Expedition 2007-2014
- Expedition (Fleet) 2015
- F-150 2009-2012
- F150 STX/FX2 base/XLT base 2013
- F150 STX/XLT base 2014
- F250/350/450/550 2008-2012
- F250/350/450/550 (XL/XLT) 2013-2016
- F-650/750 (w/ CD) 2016-Up
- Flex 2008-2012
- Focus 2008-2011
- Fusion 2010-2012
- Mustang 2009
- Taurus 2010-2012
- Lincoln
- MKX 2007-2010
- MKZ 2007-2009
- Mazda
- Mercury
- Mariner 2008-2011
- Milan 2010-2011
Axxess AXSWC Universal Steering Wheel Control Interface
Features:
- Works with Many Popular Aftermarket Receivers
- One Interface does it all – No additional interfaces needed
- Designed to be compatible with all major radio brands
- Auto detects (1) vehicle type, radio connection, and presets controls
- Ability to dual assign steering wheel control buttons
- Can be manually programmed for most vehicles
- Retains settings even after battery disconnection or interface removal
- All connections done at the radio location
- Micro “B” USB updatable
- UPC:
- Weight: 16
- Authorized Internet Dealer
Warranty: 3 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 3 Year(s) from the original date of purchase with proper return authorization.
