JL Audio MM55 MediaMaster® Series 2.8" Full-Color LCD Marine Digital Media Receiver with Bluetooth (does not play CDs)
We are a JL Audio authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
Transform Your Marine Adventure with Our Rugged, High-Visibility Marine Unit
Elevate your marine experience with our rugged, IP67-rated water-resistant unit featuring a vivid 2.8-inch full-color LCD and an intuitive, backlit interface, designed for easy, day or night operation in any environment.
Master Your Marine Sound with Precision Control and Powerful Amplification
Experience unparalleled audio control with nine channels of audiophile-quality preamp outputs, adjustable volume and subwoofer levels across three zones, and a powerful 4-channel amplifier delivering 100 watts of high-fidelity sound—perfectly tuned for your marine adventures.
Seamless Audio Integration with Advanced Tuning, Bluetooth, and Multi-Device Compatibility
Enjoy seamless audio versatility with our unit’s digital AM/FM tuner, built-in DAB+ radio for Europe, and Bluetooth streaming with Qualcomm® aptX™ for top-notch sound quality. Plus, access your music via USB 2.0 with 1 amp charging, use AUX inputs for direct audio, and integrate effortlessly with NMEA 2000-certified multifunction displays from Garmin, Lowrance, Raymarine, and Simrad.
Upgrade Your Marine Setup with Our Comprehensive Audio Accessories and Control Solutions
Enhance your marine audio experience with our range of accessories, including the MMR-40 full-color, water-resistant network controller, the MMR-25W wireless Bluetooth controller, the MMR-20-BE wired remote, and the MMR-5N2K network volume controller, all designed for superior functionality and ease of use. Plus, integrate with the MMA-1-HTML digital interface for seamless MFD navigation and controls, and control everything effortlessly with the free MM-Remote application for compatible devices.
- Maximum Power : 50 Watts
- Satellite Radio Ready : No
- RMS Power Output : 25 Watts
- Preamp Voltage : 4 volts
- Bluetooth : Yes
- Aux Input : Yes
- MP3 Playback : Yes
- WMA Playback : Yes
- Rear USB Input : 1
- Color : Black
Features:
Design & Interface
- Rugged IP67-rated water-resistant design, built to withstand harsh marine environments.
- 2.8-inch (71 mm) full-color LCD with a high-contrast design for enhanced visibility in motion.
- Intuitive interface with backlit controls for easy operation, day or night.
- Independent day and night lighting settings with separate brightness controls for the display, buttons, and optional wired remotes.
Audio Capabilities
- Nine channels of audiophile-quality preamp outputs (4-volt RMS) from three separate audio zones, each with a dedicated subwoofer output.
- Volume and subwoofer levels can be adjusted individually or together across zones.
- Onboard crossovers in each zone with adjustable high-pass (off/80/100/120 Hz) and low-pass (off/60/80/100 Hz) filters.
- Volume limit settings to cap maximum allowable volume levels for each zone.
- Tone controls for bass, midrange, treble, and balance settings.
- Zone naming for easy identification.
- Built-in 4-channel amplifier delivering 100 watts (25 watts RMS x 4) of high-fidelity sound for zones 1 and 2.
Media & Connectivity
- Digital AM/FM radio tuner with radio data system extended display info.
- Built-in DAB+ radio tuner (Europe) with support for storing up to 18 favorite stations.
- Stream audio via BLUETOOTH® with Qualcomm® aptX™ for high-quality sound.
- USB 2.0 direct-digital connections to access music files and provide 1 amp charging output.
- AUX inputs for direct analog audio signal input from external sources.
- NMEA 2000 Certified for compatibility with Garmin, Lowrance, Raymarine, and Simrad multifunction displays.
Remote Control & Interface Accessories (Sold Separately)
- MMR-40: Full-function, water-resistant (IP66-rated) network controller with full-color LCD (NMEA 2000 network).
- MMR-25W: Water-resistant (IP68-rated) wireless controller with BLUETOOTH.
- MMR-20-BE: Water-resistant (IP67-rated) wired remote controller.
- MMR-5N2K: Water-resistant (IPX7-rated) network volume controller.
- MMA-1-HTML: Digital interface for MFD navigation and controls (NMEA 2000 network).
- MM-Remote: Free full-function application controller for compatible wireless devices.
Specifications:
- Input Operating Voltage: 10 - 16 VDC
- Standby Current Draw: 100 mA
- Operating Current Draw: 15 A
- Recommended Fuse Value: 15 A
- Remote Turn-on Capacity: 500 mA (max)
- Operating Temperature Range: -4°F to +149°F (-20°C to +65°C)
- Display Size / Type: 2.8" TFT LCD, backlit
- Display Resolution: 320 x 240
- Output Channels: One stereo pair and mono subwoofer RCA plugs per zone
- Output Zones: Relative, Absolute, Fixed, or Off
- Maximum Output Voltage: 4V RMS (Relative or Absolute), Selectable 4V/2V/1V RMS (Fixed)
- UPC: 699440999755
- Weight: 5
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
