Since the beginning, Orion has been all about High Performance Car Audio and Hardcore Attitude… Attitude that is being hammered into the DNA of every piece of industrial-strength Orion Car Audio equipment, and the players that use and abuse it, the bass heads and boulevard bullies who will testify that the baddest car and the loudest system ride on the same chassis – theirs!! SPL competitors, world champions, hot rodders, urban cruisers and the ones that just want to have fun alike are motivated to roll with the bullet proof performance and legendary muscle that is Orion Car Audio.
- Diameter : 15 Inch
- Maximum Power : 5000 Watts
- Sensitivity : 87 dB
- Impedance : 4 Ohm
- RMS Power Range : 2500 Watts
- Peak Power Handling : 4000 Watts
- Number of Voice Coils : Dual
Power Handling
General Features
- 4” copper Wound Voice Coil on an Aluminum Former, High temperature PAARC (Polyester Amide, Amide Resin Coated)
- Continuous power handling will be 1500W (under rated)
- Burp power in excess of 5000W
- X-Max estimated at 30mm (total travel 4” peak to peak)
- Field Replaceable Cone / Voice coil / Spider Assembly
- Dual Flat Conex Spiders with Loop/Stitched Tinsel Leads
- Tall, wide, balanced, Foam (high density expanded polyester foam) surround for linear controlled long excursion using a Tri-Radius symmetrical edge design optimized on non-linear FEA
- Enhanced voice coil cooling system (forced convection – aluminum heat sinking – shorting rings to reduce inductive heating)
- Priced per speaker
- UPC: 093207061509
- Weight: 84
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
Do you own this product?
Write a review!
-
this is tha hardest hittn sobwoofer on th a market that i have heard it out hit my w7 by a long shot needs a lot of power and make sure u got a sturdy box a pre fab wont hold up to it box needs to be built strictly to tha specs also
-
DAMNNNN!!!!! THESES HIT!!!IVE GOT 2 of these hooked up to 2 Hifonics bxi2608D in the back of my tahoe and they will make ur ears hurt and take the breath out of you......u wont believe it to you hear and feel them....make sure you get a box built to its specs or else the box will break.....The bass is pretty good not the cleanest but is one of the loudest..... If you want SPL buy this sub.... If u want clean bass get jl audio or diamond audio.....
-
tengo dos 15.4 y solo un jl audio 1000/1 en 99 tahoe y es mejor que Audio bahn,kicker,Maaudio,cerwin vega y Mtx,
-
this sub is unbelievable.. all these people saying that there 2 12s are being heard from blocks away.. nawww this sub is heard and felt from blocks away.. my homies tell me i rattle the shit in their house when im cruising up.. not when im parked out front.. cruisin up.. it broke off a piece of my trunk! if u like competing and want top of the line subs.. look no further
-
i put two these in my tahoe about a month ago and they blowed out all my back glass this is the real shit they dont play at all
-
i have four of these babys in my car but i cant push out enough power for them i have over 7000 watts of power pushin them n dat ain enough really great subs
-
i just got my 2 subs yesterday and they are way to much for me to handle in my 02 tahoe, the bass is crazy and the sound is nice.. I cracked my back window last night trying to empress some chicks.. I did and now its costing me $450 for the back window...awsome speakers
-
i have one of these bad boys in a 5.5 cubic foot custom made box and it ran me out of my car i have a 05 malibu classic i have 3 w3v3 12s and 2 w6v2 12s and the orion took them out in hittin hard but sound quality im stickin wit jl i have a hifonics 2008 bxi class d amp on it ita not turn up and i out slapped my friend wit 2 l7 on a 3000 power acoutic i would buy another but one is all i need to beat up the block lol
-
Just install these these babies. I almost run out of my car! Wow great buy people...keep it up Orion. Can't wait to get two more.
-
Awesome!!! Absolutely loved it!!!
-
This thing is a beast I have one in my 07 jeep using a hifonics 5 k pro it is tearing my jeep apart. I want to get another one but don't have the room if I want to stay in the stock division. My buddy took the national championship in 2014 with this sub. And I'm using that box.
