- Diameter : 12 Inch
- Low Frequency Response : 20 Hz
- High Frequency Response : 180 Hz
- Sensitivity : 92 dB
- Impedance : 4 Ohm
- RMS Power Range : 400 Watts
- Peak Power Handling : 1400 Watts
- Number of Voice Coils : Dual
Power Handling
- Peak: 1400 Watts
- RMS: 400 Watts
Features
- Woofer Cone Material: Interlaced Basalt/Carbon Fiber Reinforced IMPP Cone
- Woofer Cone Design: Cone Reinforcement Arcs
- Surround: Wide Roll, Three-Layer Fiber Woven Radial
- Voice Coil: 4-Layer, Long Voice Coil
- Voice Coil: Wire Copper
- Voice Coil Bobbin: Phenol Resin Coated Glass Cloth
- Damper (Spider): Aramid Fiber
- Damper Ring: Yes
- Top Plate: Standard
- Projected Pole Yoke with Vented Pole
- Magnet Construction: Double Mass High-Power (83oz)
- Basket Design: Stamped Basket with Magnet Cover
- Gasket ABS
- Wire Terminals: Integrated Single-Sided Silver Compression Terminals
- Frequency Response: 20 Hz to 180 Hz
- Sensitivity: D4 (92dB)
- Ohm Rating: D2 (1 or 4 ohm) D4 (2 or 8 ohm)
- Recommended Enclosure: 0.85 - 1.75 Cubic Feet
- Dimensions: 327 mm x 172 mm
- Mounting Depth: 153 mm
- Accessory Grill: UD-G308
- Priced per speaker
- UPC:
- Weight: 0
- Authorized Internet Dealer
Warranty: 0 Months Onlinecarstereo.com warranty.
0 Months warranty from Onlinecarstereo.com implies that repairs must be returned to Onlinecarstereo.com, not the manufacturer. More information can be found in our help section under returns & warranties.
What's not covered : Misuse, abuse, defacement, physical damage of any kind, and improper installation / operation. Video and multimedia equipment with damaged or cracked screens.Subwoofers and speakers are not warrantied if the defect is due to physical damage.
Do you own this product?
Write a review!
-
I have two of these bridged to 4ohm to a memphis pr300.2 amp. Its pushing 600 rms brigded. These 12's are so loud! I only have the gain on the amp at 1/4 the way up and its hard to think straight. I have them in a sealed box and they slap hard in tha trunk. Wonder how loud they would be wit a ported box and a bigger amp.
-
I have two of these in a bandpass box and they pound with only a 760 watt 2-channel Pioneer amp pushin them, great buy for $75.00, would recommend them to anyone who wants good subs for cheap.
-
i have two of these on a 500 watt mono block jl audio amp. the speakers are in a ported box and they pound like crazy. i have always liked pioneer period. its a very good brand to buy. im always satisfied.
-
These speakers HITTTTT! i have 4 in a grand marquis with 1 kenwood 1800 watt amp. First, dont let anybody tell u that those kenwood amps are bad, they HIT!, just run a 0 gauge wire to a distribution block and u good to go. but these speakers make my windshiled wipers jump. So if you want something that beats, that is not too expensive, and u have enough power to push em, get this one.
-
I have 2 of these being pushed by a MTX Jackhammer JH600 at 4ohms 350watts. Man i tell these things are the best for the price you pay. i can't complain at all. the only thing i can say is WOW. especially if you consider that they only have 350w going to them. when i pull in my driveway i can shake my house. Best bang for the buck.
-
im runnin 2 of these joints in my marquis with a hifonics 1200 watt amp they cool and all but im gonna upgrade to the hifonics olympus 15s so i can kill whoever ears in my car especially with all the tweeters and mids i got inside
