A 435-watt, four-channel, full-range powerhouse, the GX-A604 – with on-board variable electronic crossovers and variable Bass EQ on the rear channels – is certainly a versatile system building tool. With all that power inside a 2-1/16" (52mm) high, 8-1/8" (206mm) wide and 11 13/16" (300mm) deep package, the GX-A604 is easy to install yet can serve as the foundation of a truly sophisticated sound system. Features include a cast-aluminum heat sink, built-in electronic crossover networks and bass boos circuits.
Description:
• 4-Channel Car Amplifier
• 4 ohms: 60 watts x 4 chan
• 2 ohms: 85 watts x 4 chan
• Bridged, 4 ohms: 170 watts x 2 chan
• Max power output: 435 watts
• 4, 3 or 2 channel operation
• 8 gauge power and ground wiring is required for installation
- Maximum Power : 435 Watts
- Low Frequency Response : 20000 Hz
- High Frequency Response : 20 Hz
- Number of Channels : 4
- Frequency Response : 20-20000 Hz
- Built In Crossovers : Yes
- Channel Separation : Yes
- RMS Power Range : 60-170 Watts
- Amplifier Class : AB
- Fuse Rating : 20 A
Product Highlights:
- 4-channel car amplifier
- 60 watts RMS x 4 at 4 ohms (85 watts RMS x 4 at 2 ohms)
- 170 watts RMS x 2 at 4 ohms in bridged mode (4-ohm stable in bridged mode)
- switchable high-pass filters (80 Hz, 12 dB/octave) on front channels
- variable high- and low-pass filters (32-320 Hz, 12 dB per octave) on rear channels
- switchable bass boost (0, 12 dB at 45 Hz) on rear channels
- preamp and speaker-level inputs
- fuse rating: 20A x 2
- 8-gauge power and ground leads recommended — wiring and hardware not included with amplifier
- 11-13/16"W x 2-1/16"H x 8-1/8"D
Includes:
- 4-Channel amplifier with two 20A ATO fuses installed
- Two 8.25" Speaker-level input harnesses
- 4 Self-tapping screws (Length=3/4")
- Owner's Manual
- UPC: 050036319539
- Weight: 7
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
