Hertz  DCX690.3

Dieci Series 6x9" 180W Peak Power Handling 4 Ohm, 3-Way Coaxial Car Speakers

Item #54270

Condition:   Brand New

Product Highlights

  • Dieci Series
  • 6x9" size
  • 180W peak power
  • 4 Ohms impedance
  • 3-way coaxial design

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.

$189.99

Reg. Price $225.00  Save $35.01
Special Order Item

Estimated shipping time is 7-10 days. Risk Free

Add Extended Warranty
  Free 2-Years Warranty Included!

Starting at $18/mo with . Check your purchasing power

No Credit needed for Learn More


Hertz Authorized Dealer

Huge Saving on Other items:


Brand Banner

Hertz DCX690.3 Dieci Series 6x9" 90W RMS (180W Peak Power Handling) 4 Ohms, 3-Way Coaxial Car Speakers


Alpine Banner for OCS

We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • • (2) 6x9" 4 Ohms 3-Way Car Speakers
  • • (2) Grilles
  • • (2) Grille mounting rings
  • • Grille putty
  • • (8) 3/4" Screws
  • • (8) Speed clips
  • • Owner's manual
Oversized Magnetic Group

Hertz DCX 690.3 Dieci series car audio coaxials use an oversized magnetic group, TPU (Thermoplastic polyurethane) surround, a 60 mm diameter midrange, and a PEI dome tweeter. The result is linearity, wide dispersion, and extra-ordinary efficiency not found in traditional coax components. An involving, emotional sound, even at high SPL levels. An authentic 3-way coax capable of reproducing a wide frequency spectrum.

With Precision and Clarity.

With its wide dispersion and exceptional efficiency, surpassing conventional coaxial components, this speaker offers an immersive, emotionally engaging sound experience even at elevated SPL levels. As an authentic 3-way coaxial system, it excels in reproducing a broad frequency spectrum, ensuring every nuance of your audio content is faithfully delivered with precision and clarity.



Physical Specifications
  • • A1: 237 mm (9.3 in.)
  • • A2: 162 mm (6.4 in.)
  • • B1: 224 mm (8.8 in.)
  • • B2: 153 mm (6.0 in.)
  • • C: 98 mm (3.9 in.)
  • • D: 77 mm (3.0 in.)
  • Diameter : 6x9 Inch
  • Sensitivity : 93 dB
  • Impedance : 4 Ohm
  • Frequency Response : 45-21000 Hz
  • Peak Power Handling : 180 Watts
  • Design : 3 Way
  • RMS Power Handling : 90 Watts

Features:

  • Large motor assembly for mobile voice coil control.
  • Pure copper voice coil, wound on conex former, for maximum lightness.
  • Water-repellent treated paper cone.
  • TPU surround, for wide excursion and resonance damping.
  • 60 mm paper tweeter with ferrite magnet.
  • Supertweeter with PEI dome, for compactness and energy at high frequencies.
  • DIN size basket protected by abrasion-proof dust paint.
  • Tin-plated, high current terminals.
  • Silver-plated lead wires for maximum reliability and conductivity.
  • Butyl rubber protective cover, against crashes and abrasions.
  • Epoxy glue for basket and motor system provides perfect coupling.
  • Low carbon content plates for maximum magnetic permeability and high heat dissipation.



Specifications:

  • Power Handling - Peak W: 180
  • Power Handling - Continuous W: 90
  • Impedance: 4 ohms
  • Frequency response Hz: 45 ÷ 21k
  • Sensitivity dB SPL: 93
  • Voice coil Ø mm (in.): 25 (1.0
  • Woofer size mm (in.): (6.0 x 9.0)
  • Tweeter size mm (in.): 60 (2.5)
  • Woofer magnet: High density flux ferrite
  • Tweeter magnet: High density flux ferrite
  • Woofer cone: Water-repellent pressed paper
  • Tweeter dome: Water-repellent pressed paper



Electro-acoustic Specs:

  • Diameter (D): 170 mm
  • DC Resistance (Re): 3.4 Ohms
  • Resonant Frequency (Fs): 66 Hz
  • Equivalent Volume of Compliance (Vas): 25.7 liters
  • Mechanical Mass (Mms): 16.5 grams
  • Mechanical Compliance (Cms): 0.35 mm per Newton
  • Force Factor (BL): 3.9 Tesla meters
  • Total Q Factor (Qts): 1.12
  • Electrical Q Factor (Qes): 1.55
  • Mechanical Q Factor (Qms): 4.06
  • Sound Pressure Level (SPL): 93 dB
  • UPC: 8018823104197
  • Weight: 7.01
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
**Speakers purchased and installed by an authorized Hertz dealer will have a three (3) year limited warranty from the original date of purchase.
