Hertz CX690 Cento Series 6"X9" 300W Peak Power Handling 4 Ohms 3-Way Coaxial Car Speakers
We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!
What's Inside?
- • (2) Hertz CX690 Cento Series 6X9" 3-way Car Speakers
- • (2) Grilles
- • (2) Grille mounting rings
- • Grille putty
- • (8) 3/4" Screws
- • (8) Speed clips
- • Owner's manual (English/ Spanish/ French/ German/ Italian/ Portuguese/ 28 Others)
- • Template on box
Powerful Performance
The Hertz CX690 is a high-performance car audio coaxial speaker system with exceptional sound quality and powerful performance. With its innovative design and advanced technologies, the CX690 ensures an immersive audio experience in your vehicle.
Frequency Response
Spanning from 40 Hz to 23 kHz, the expansive frequency response of these speakers ensures an immersive audio experience that captures every nuance and detail of your music, from the deepest bass notes to the crispest highs, providing a truly lifelike sound reproduction that brings your favorite songs to life like never before.
Physical Specifications
- • A: 238 mm (9.37 in.)
- • B: 224 mm (8.82 in.)
- • C: 95 mm (3.74 in.)
- • D: 78.5 mm (3.09 in.)
- • E: 268 mm (10.55 in.)
- • F: 29 mm (1.14 in.)
- Diameter : 6x9 Inch
- Sensitivity : 93.5 dB
- Impedance : 4 Ohm
- Frequency Response : 40-23000 Hz
- Peak Power Handling : 300 Watts
- Design : 3 Way
- RMS Power Handling : 100 Watts
Features:
- 6×9 in. semi-pressed paper elliptical cone SPP-M (Semi Pressed Paper-Mica) enhanced with Mica powder for an excellent balance between lightness and damping.
- Wide rubber suspension engineered for a long excursion and excellent sound damping.
- High-density flux ferrite magnet combined with low-carbon polar plates for reduced distortion at high power levels.
- Basket with metallic finish acoustically combined with a rubber magnet cover for total damping of spurious vibrations.
- 40 mm (1.58 in.) dome tweeter for efficient distortion-free mid-high frequency reproduction.
- 20 mm (0.8 in.) dome supertweeter to maximize the level of very high frequencies in horizontal installations.
- Tweeter faceplate geometry optimized with FEM simulations (Finite Element Modeling), to provide an extremely linear frequency response in off-axis installations.
- Provided elegant grille made with high-resistance ABS plastic structure with a metallic finish combined with a protective metal mesh.
Specifications:
- Power Handling - Peak W: 300
- Power Handling - Continuous W: 100
- Impedance: 4 ohms
- Frequency response Hz: 40 ÷ 23k
- Sensitivity dB SPL: 93.5
- Woofer size mm (in.): (6 x 9)
- Tweeter size mm (in.): 40 (1.58)
- Supertweeter size mm (in.): 20 (0.8)
- Woofer Voice Coil Ø mm (in.): 30 (1.2)
- Tweeter voice coil Ø mm (in.): 28 (1.1)
- Woofer magnet: High density flux ferrite
- Tweeter magnet: Neodymium
- Woofer cone: Semi Pressed Paper-Mica
- Tweeter dome: PEI
- Supertweeter dome: PEI
Electro-acoustic Specifications:
- Diameter (D): 139 mm
- DC Resistance (Re): 3.3 ohms
- Resonant Frequency (Fs): 70 Hz
- Voice Coil Inductance (Le): 0.2 mH
- Equivalent Air Volume (Vas): 11.1 liters
- Moving Mass (Mms): 13 grams
- Mechanical Compliance (Cms): 0.34 mm/N
- Force Factor (BL): 4.9 T*m
- Total Q Factor (Qts): 0.67
- Electrical Q Factor (Qes): 0.83
- Mechanical Q Factor (Qms): 3.3
- Sound Pressure Level (SPL): 93.5 dB
- UPC: 8018823126687
- Weight: 8
- Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
**Speakers purchased and installed by an authorized Hertz dealer will have a three (3) year limited warranty from the original date of purchase.
