Infinity  REFERENCE123WSL

Reference Series 12" 1200W Peak Power Handling 2 or 4 Ohms (Switchable-Impedance) Shallow-Mount Component Car Subwoofer

Item #93758

Condition:   Brand New

Product Highlights

  • Reference Series
  • 12" Subwoofer
  • 1200W Peak Power
  • 2 or 4 Ohms Switchable Impedance
  • Shallow-Mount Design

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
LIMITED TIME SALE!

Get 10% OFF on this item! Use coupon code OPTNOW

$279.95

Special Order Item

Estimated shipping time is 7-10 days. Risk Free

Add Extended Warranty
  Free 2-Years Warranty Included!

No Credit needed for Learn More


Infinity Authorized Dealer

Huge Saving on Other items:


Brand Banner

Alpine Reference Series 12" 400W (1200W Peak Power Handling) 2 or 4 Ohms (Switchable-Impedance) Shallow-Mount Component Car Subwoofer


We are a Alpine authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • Infinity Reference 12" Subwoofer
  • Owner's Manual with installation instructions
  • Mounting Hardware (screws, clips, etc.)
  • Warranty Card
Alpine_UTE-73BT
Deliver deep, Powerful bass

Infinity Reference subwoofers deliver deep, powerful bass that will elevate your system to the next level, utilizing a proprietary cone design and high-roll surrounds for exceptional efficiency, requiring less power to achieve impressive performance. These subwoofers excel in both sealed and bandpass box configurations, providing punchy, accurate bass, and feature SSI™ (Selectable Smart Impedance), an exclusive switch that allows you to choose the optimal 2 or 4 ohm impedance for your amplifier and overall system layout.

Providing Punchy and Accurate bass

These subwoofers excel in both sealed and bandpass box configurations, providing punchy, accurate bass, and feature SSI™ (Selectable Smart Impedance), an exclusive switch that allows you to choose the optimal 2 or 4 ohm impedance for your amplifier and overall system layout.

Alpine_UTE-73BT
  • Diameter : 12 Inch
  • Sensitivity : 84 dB
  • Impedance : 2 or 4 Ohm
  • Frequency Response : 30 - 400 Hz
  • Peak Power Handling : 1200 Watts
  • Shallow Mount : 12 Inch
  • RMS Power Handling : 400 Watts

Features and Specs:

  • Size: 12-inch
  • Impedance (Ohms): 2, 4
  • Cone Material: Aluminum
  • Surround Material: Rubber
  • Free-Air: ---
  • Dual Voice Coil: Yes
  • Sensitivity: 84 dB at 1 watt
  • Frequency Response: 30 - 400 Hz
  • Max RMS Power Handling: 400 Watts
  • Peak Power Handling (Watts): 1200 Watts
  • Top Mount Depth (inches): 3 1/4
  • Bottom Mount Depth (inches): ---
  • Cutout Diameter or Length (inches): 11
  • Frame Width: ---
  • Frame Length: ---
  • Vas (liters): ---
  • Fs (Hz): ---
  • Qts: ---
  • Xmax (millimeters): ---
  • Parts Warranty: 1 Year
  • Labor Warranty: 1 Year
  • Box Requirements:
  • Ideal Sealed Box Volume (cubic feet): N/A
  • Minimum Sealed Box Volume (cubic feet): N/A
  • Maximum Sealed Box Volume (cubic feet): N/A
  • Ideal Ported Box Volume (cubic feet): N/A
  • Minimum Ported Box Volume (cubic feet): N/A
  • Maximum Ported Box Volume (cubic feet): N/A
  • UPC:
  • Weight: 19
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for replacement within 2 Year(s) from the original date of purchase with proper return authorization.
