Hertz  HCP 1D

Compact Power Series 500Wx1 RMS @ 2 ohms, Class D Mono Subwoofer Amplifier

Item #54233

Condition:   Brand New

Product Highlights

  • 500W RMS @ 2 ohms
  • Class D
  • Mono Subwoofer Amplifier

  Free 2-Years Warranty Included!
60 DAYS Returns Accepted.
FREE Lifetime Tech Support.
FREE Shipping (No Minimum).
60 DAYS Price change protection.
Special offer:

$269.99

Reg. Price $360.00  Save $90.01
In Stock
In Stock

Only 1 left
Add Extended Warranty
  Free 2-Years Warranty Included!

Starting at $25/mo with . Check your purchasing power

No Credit needed for Learn More


Hertz Authorized Dealer

Huge Saving on Other items:


PAC Banner

Hertz HCP 1D 500Wx1 RMS @ 2 ohms, Class D Mono Subwoofer Amplifier


Alpine Banner for OCS

We are a Hertz authorized dealer so you get up-to-date, fully warrantied products. Shipping is free to the lower 48 states on everything you order!

What's Inside?
  • •Mono amplifier
  • •(4) 25-amp ATO fuses (2 installed)
  • •7" Speaker level input harness
  • •4mm Allen wrench
  • •2mm Allen wrench
  • •(4) M4 x 20mm mounting screws
  • •(4) Flat washers
  • •Warranty Card
  • •Owner's Manual
Advanced D-class Technology

HCP 1D is a mono D Class car audio amplifier , with an incredibly minimized size heat sink. All the Hertz Compact Power amplifiers are assembled with high-quality components and feature a complete and by-passable crossover system. The dissipation system is optimized with the heat being transferred to the heat sink and then dissipated through the sides of the amplifier.

Designed to Work in Multiple Configurations

HCP 1D has been designed to work in multiple configurations. More specifically, it features Hi-Pass pre-amplified outputs, providing the ability to create a Band-Pass on the front woofer. Besides, using the HRC accessory (Hertz Remote Control), the subwoofer volume can be remote controlled with extreme preciseness.

  • Maximum Power : 1400 Watts
  • Low Frequency Response : 50-250 Hz
  • High Frequency Response : 50-250 Hz
  • Number of Channels : 1
  • Frequency Response : 10-22000 Hz
  • Built In Crossovers : Yes
  • RMS Power Output : 550x1 Watts
  • Amplifier Class : D
  • Fuse Rating : 50x1 A
  • XP750-SE OFFER : Yes

Features:

  • Compact design built from extruded aluminum heatsink with the top side ensuring effective transfer of the heat.
  • Special balanced high-noise rejection input circuitry on the Pre-In or Speaker-In inputs.
  • Speaker-In (for OEM head units) and RCA-In (for Aftermarket head units) inputs.
  • Selectable ART, Automatic Remote Turn-On/Off function, automatically turns on and off the amplifier when the OEM radio turns on and off (can be enabled/disabled, with only Speaker-In inputs).
  • Power supply featuring multiple winding transformer, Low-ESR 105°C capacitors, D-Class 2 ohm stable output stage.
  • Pre-outs, also available when using Speaker-In level inputs, equipped with Hi-Pass filter with adjustable 12 dB/Oct. slope with continuity between 50 and 250 Hz, providing the ability to create Front + Sub multi-amplification active systems.
  • Selectable full range power output, for dual-mono powerful audio systems.
  • Bass Boost (50 Hz) adjustable to 12 dB, to increase the subwoofer punch.
  • 24 dB continuous adjustable (50 to 250 Hz) Lo-Pass filter.
  • SUBSONIC filter (24 dB – 25 Hz), removes very low subsonic frequencies from music signal to prevent damage to the subwoofer.
  • Continuous adjustable PHASE control (0 to 180°); it optimizes alignment of woofer bass frequencies with sub ones.
  • Optional Remote Volume Control (HRC); providing the ability to adjust subwoofer volume level from the dashboard.



Specifications:

  • Channel mode: 1
  • Output Power (RMS) @ 14.4 VDC
    • 1 Ch: 380 W x 1 (4 ohms)
    • 1 Ch: 700 W x 1 (2 ohms)
  • Filters
    • Bypass: Yes
    • Hi-Pass: ---
    • Lo-Pass: 50 ÷ 250 Hz @ 24 dB/Oct.
    • Band-Pass: ---
  • Subsonic: 25 Hz @ 24 dB/Oct.
  • Distortion - THD (100Hz @ 4 ohms): 0.2%
  • S/N Ratio (A weighted @ 1V): 100 dB
  • Damping factor (100Hz @ 4 ohms): 80
  • Size W x D x H mm (in.): 215 x 190 x 50 (8.46 x 7.48 x 1.97)
  • UPC: 8018823110556
  • Weight: 8
  • Authorized Internet Dealer
Warranty: 2 Year(s) Warranty.
This item is accompanied by a manufacturer's warranty. If it is found to be defective, it may be returned to OnlineCarstereo.com for repair within 1 year from the original date of purchase with proper return authorization.
